1.6/5.6(L9)系列射頻同軸連接器
SERIES RF COAXIAL CONNECTORS

1.6/5.6(L9)型產品是一種具有螺紋、卡鎖機構的連接器，它廣泛應用于郵電通信設備、數字配線裝置，無線電儀器等射頻回路中連接射頻同軸電纜用，并能與IEC60169-13規定的產品相互換。
1.6/5.6 type products whether one have whorl, card lock connection device of organization, it apply to post and telecommunications communication equipment, figure buy the line device extensively, The radio instrument waits until joining the coaxial cable of the radio frequency to use in the radio frequency return circuit, And can change each other with the products that IEC60169-13 stipulate.

主要技術特性 TECHNICAL CHARACTERISTICS
溫度范圍 Temp.range -40～+85°C
振 動 Vibration 100m/s2 (10～500Hz)
特性阻抗 Impedance 75Ω
頻率范圍 Frequency Range DC～1GHz
工作電壓 Working Voltage 330V max (有效值)
耐 壓 Withstand Voltage 1000V rms (海平面有效值)
接觸電阻 Contact resistance
內導體之間 Center Contact ≤ 4 mΩ
外導體之間 Outer Contact ≤ 2 mΩ
絕緣電阻 Insulation resistance ≥ 10000 MΩ
耐用性 Durability(mating) ≥500次

材料與涂覆 MATERIAL & PLATING
殼體 shell 黃銅 brass 鍍亮鎳 nickel plated
插針 contact pin 黃銅 brass 鍍硬金 gold plated
插孔 socket 鈹青銅 beryllium 鍍硬金 gold plated
彈性接觸件elastic contact鈹青銅或錫青銅beryllium or tin brass鍍硬金 gold plated
絕緣體 insulator 聚四氟乙烯 PTFE
壓接套 crimping suite 銅合金 copper alloy 鍍鎳或鍍金 nickel or gold plated
o型密封件 o-ring sealing 硅橡膠 6146 silastic

適用技術標準 APPLICABLE STANDARD
CECC 22240;
IEC 60169-13;
DIN 47295.
